    MCC Panel (Motor Control Center)

    The Motor Control Canter (MCC) Panel is a panel consisting of one or more 'enclosed sections'. All of these sections have a communal power bus.Also, these are mainly composed of motor control units.We offer these MCCs with the option of number of latest technology starters such as AC/ DC drive starter(covariant frequency drive), direct - on - line starter, soft starter, star delta starter, submersible starter, etc.Their main function is related to induction motors, which inrush starting current is minimized. In addition, there are a number of motor protection equipment in the Motor Control canter(MCC) Panel, such as overload protection, short circuit protection, and single phasing protection, that are useful in safeguarding the motor.

    Our MCC involves following features

    Remote control operation facility
    MCCB for protection
    Change over switch for circuit change from mains to DG and vice-versa
    Direct on-line starters that include MCB, contactor, thermal overload relay and connectors
    Bus Bars of proper rating duly covered with acrylic sheet for safety
    Aluminium strip for earthing
    Panel light and fan for ventilation
    Many more features that solve many practical problems

    These MCC units comprise:

    Full voltage non-reversing and full voltage reversing starters
    AC variable frequency drives
    PLC I/O chassis
    Solid-state motor controllers
    Lighting panels
    Transformers
    Analog or digital metering
    Feeder circuit breakers
    Feeder fusible disconnects

    Technical Specifications of Motor Control Centre Panel:

    Operational Current: 32A to 1600A
    Ambient Temperature: 40.50 degree Celsius in single and double front
    Withstand Capacity: 16KA to 100 KA
    Degree of Protection: As per IS Standards
    Types of Starters Include: Automatic Star Delta, Direct On-line, Soft Starters, Varied Frequency Drives, Stator Rotor Starters and Auto Transformer Starters
